G3 Series Linear High Bay
Latest generation linear high bay with advanced optics and energy saving capabilities. Perfect for aisle lighting in warehouses and distribution centers.
Wattage
100W, 200W, 240W, 300W
Efficacy
140 lm/W
Warranty
5 Year (10-Year Option)
Certifications
DLC Listed
Specifications
| Wattage | 100W, 200W, 240W, 300W |
| Efficacy | 140 lm/W |
| CCT | 3500K-5000K |
| Warranty | 5 Year (10-Year Option) |
| Voltage | 100-277V / 200-480V, 50/60Hz |
| IP Rating | IP40 |
| Operating Temp | -10°F to +120°F |
| Listings | DLC Listed |
| Power Factor | >0.95 |
| Dimming | 0-10V |
